Rugged 8-Port Ethernet Switch 4 SFP Fiber Ports for IP Camera Systems

Industrial 8-Port 10/100/1000T + 4-Port 1000X SFP Managed Ethernet Switch

LNK-IMC408GL-SFP Managed Industrial 8-Port Ethernet Switch Overview

The LNK-IMC408GL-SFP series is a hardened, managed, eight-port, 10/100/1000Base-T switch with four SFP fibre ports. It is built for industrial and outdoor networking. It features eight Gigabit Ethernet ports (auto-negotiating and MDI/MDI-X) and four 1000Base-X SFP slots supporting single- and multi-mode fibre. Designed for use in harsh environments, it provides a reliable connection for IP cameras, wireless access points, and remote networks, offering advanced management and flexible fibre connectivity.

LNK-IMC408GL-SFP Managed Industrial 8-Port Ethernet Switch Features

• Supports 8×10/100/1000Base-T RJ45 ports and 4×1000Base-X SFP fiber ports
• RJ45 ports support full/half-duplex , auto-negotiation , and Auto MDI/MDIX functions
• DIP switch for serial port configuration
• Supports 16K bytes jumbo frames for improved transmission efficiency
• Compliant with IEEE 802.3az Energy Efficient Ethernet (EEE) standard for reduced power consumption
• IP40-rated aluminum housing for enhanced durability and protection
• Wide-range 12–48V DC power input for flexible deployment
• DIN-rail mount design for easy industrial installation
• Operating temperature range: -40°C to +80°C (-40°F to +176°F) for harsh environments

LNK-IMC408GL-SFP Managed Industrial 8-Port Ethernet Switch Technical Indexes

LNK-IMC408GLP-SFP Managed Industrial 8-Port Ethernet Switch Ordering Information

LNK-IMC408GLP-SFP Managed Industrial 8-Port Ethernet Switch Application

After-Sales and Warranty Policy

It is composed of online customer service and telephone customer service, providing product consultation,

remote technical support, maintenance and acceptance services.

Service Policy: Three-month replacement and three-year warranty.

Replacement: Within three months of purchasing a series of products, after testing the product failure by technicians and man-made damage

caused by non-natural disasters, the purchaser can directly go to the purchasing point to replace the same type of products.

Or a product of comparable performance. If there is no trouble in product testing, the original sample will be returned.

Warranty: Man-made damage caused by non-natural disasters, our company's free warranty period is 1 year.

[The following circumstances do not fall within the scope of replacement and free maintenance]

1.Damage caused by operation and maintenance not in accordance with the instructions in the product manual.
2.Damage caused by human factors, such as inappropriate voltage input, water intake and breakage.
3.Damage to products caused by natural disasters, such as lightning, earthquakes, fires, etc.
3.Unauthorized alteration of the inherent settings or repair without the company's permission.
4.Products beyond the scope of free maintenance.
5.Damage caused by transportation, loading and unloading during repairs sent by customers.
6.The product bar code or model on the product warranty card does not conform to the product itself.
7.Failure or damage caused by other non-product problems such as design, technology, manufacturing and quality.
